General outline of POLLIGHT FALCON
The FALCON series lighting fittings were designed by Polish designers and engineers. Production takes place in Poland, in a factory with implemented ISO quality standards, required by the research unit SEP – BBJ under the ENEC certificate.
The main idea behind the FALCON luminaire concept is to achieve structural and functional parameters that allow optimization in terms of: saving electricity, reducing investment costs and improving road and pedestrian safety.
High technical parameters and wide possibilities of using FALCON luminaires are the result of a combination of POLLIGHT implementation experiences in the field of road lighting and the needs and requirements of the Polish lighting market.
FALCON fittings, due to the modern design and use of proven components, are placed at the top of the high quality products characterized by:
- High durability
- Lifetime estimated to be 20 to 30 years
- High light efficiency
- Variety of photometric parameters
Construction parameters:
-
Body made of high pressure aluminium casting
-
Powder paint for selected colour from RAL pallet
-
Opening/closure of the electrical chamber by means of buckles/clamps without tools
-
Flat tempered glass sheet
Powder-painted coating is UV-resistant and atmospheric. Dedicated for outdoor use.
-
Mounting bracket for mounting on the boom and 48-76 mm diameter pole, adjustment of the angle of inclination of the mounting: 135O
-
Anti-condensing valve
-
IP66 housing tightness
-
IK10 impact strength
-
Universal socket in standard NEMA ANSI C136.41
-
Universal socket in standard ZHAGA D4i / NEMA
-
Overvoltage protection 10/15/20 kV
-
Operating environment temperature Ta = 50OC
Electrical parameters:
Protection class I/II
Power ≤ 215 [W]
Rated power supply voltage 230 [V]
Power factor 0,9 – 0,99 [-]
Frequency 50 / 60 [Hz]
Photometric parameters:
Light stream: up to 40,000 [lm]
Light efficacy: ≤ 188 [lm/W]
CRI: > 70 [-]
CCT: 2000 – 5700 [K]
Functional parameters
-
Maintaining a constant luminous flux value in time (CLO)
-
Autonomous multi-stage power reduction at specified night hours
-
luminaire communication interface: DALI/DALI2/0-10V/1-10V
-
Cooperation with wireless and wired control systems
Durability parameters:
-
Durability of light sources > L90 100,000 [h]
Additional information:
The POLLIGHT FALCON lighting luminaire has a wide range of configuration possibilities for components. The technical specification included in this catalogue sheet exhausts all accessories variants of the housing.
Dimensions:
FALCON-1
length (mm): 500
width (mm): 280
height (mm): 100
power (W): up to 70
Own weight (kg): ≤ 5,5
FALCON-2
length (mm): 580
width (mm): 340
height (mm): 100
power (W): up to 120
Own weight (kg): ≤ 7,5
FALCON-3
length (mm): 730
width (mm): 350
height (mm): 100
power (W): up to 215
Own weight (kg): ≤ 9,5
Being a certain quality of its services and products Pollight is the leader among the performers who disposing of payments for the modernisation carried out for partial charges, (up to 120 months).
The same Pollight functions as a financing institution modernising and building lighting infrastructure.
Guarantee period on installed devices reaches 10 years, often exceeding the period of possible funding for modernisation.
